ROLLER SHUTTER DOOR FORMING MACHINE (WITH PERFORATED MACHINE)

Thickness: 0.8-1.0mm
Forming stations: 12
Cutting type: hydraulic cutting with servo motor
Drive type: gear transmission system
Forming speed: 12-15m/min

  • HUAZHONG

  • 8455229090

Availability:
Inquire

PRODUCT DESCRIPTION

Uncoiler---Punching machine---Feeding guide---Roll forming---Cooling system---Hydraulic cutting with servo motor---Run out table


TECHNICAL DETAILS

One-piece frame

Embedded hydraulic station: 4KW, 380V, 50/60 HZ, 3 Phase

Embedded electric cabinet: Delta PLC control system, Delta inverter

Cantilever console: Delta touch screen

Uncoiler: 3 Tons

Thickness: 0.8-1.0mm

Forming stations: 12

Main motor power: 5.5KW, 380V, 50/60 HZ, 3 Phase

Cutting type: hydraulic cutting with servo motor

Forming speed: 12-15m/min

Forming speed (including punching): 8-10m/min

Drive type: gear transmission system

25 Tons punching machine

Cooling system


MACHINE PHOTOS

roller shutter door roll forming machine (2)

roller shutter door roll forming machine (8)
