Uncoiler:10 Tons uncoiler with leveling and servo feeding
Forming station: 50
Driving type: gearbox
Fly saw cutting with servo motor
Hydraulic punching

Thickness:1.0-2.0mm，galvanized sheet
Forming station: 27
Cutting type:Hydraulic flat cutting
Drive type:170 gear box transmission
Forming speed: 25m/min

Thickness: 0.8-1.5mm
Forming stations: 28
Drive type: chain transmission system
Hydraulic cutting
Forming speed: 4-8m/min

Material thickness: 1.8-2.0mm, galvanized steel
Forming station: 22
Driving type: Gearbox universal joint transmission
Cutting type: Saw cutting with servo tracking

Thickness: 2.0mm
Forming station: 50
Cutting type: Fly saw cutting with servo motor
Drive type: gearbox transmission system
Forming speed: 5-7m/min

Material thickness: 1.8-2.0mm, galvanized steel
Forming station: 22
Driving type: Gearbox universal joint transmission
Cutting type: Saw cutting with servo tracking

Material thickness: 1.8-2.0mm, galvanized steel
Forming station: 22
Driving type: Gearbox universal joint transmission
Cutting type: Saw cutting with servo tracking

Thickness:1.0mm，galvanized steel
Forming stations: 32
Cutting type: Hydraulic cutting
Drive type: Gearbox transmission
Forming speed: 8-12m/min
