Overall dimensions:6000mm*1500mm*800mm(L*H*W);
Weight: About 1200kgs;
Cross beam, weldable: 0-160mm;
Beam height: 50-160MM;
P-beam:30✘50.40✘60;

Stations: 12
Galvanized steel: 0.8-1.2mm
Cutting type: hydraulic cutting
Transmission by gear
Working speed: 15-20m/min (including cutting)

Stations: 12
Galvanized steel: 0.8-1.2mm
Cutting type: hydraulic cutting
Transmission by chain
Working speed: 15-20m/min (including cutting)

Frame:One-piece frame
Driving type: gear transmission
Cutting type:Hydraulic cutting
Material thickness:0.8-1.0mm
Forming speed:10-15m/min

Forming station: Upper 14-16, lower 25
Thickness of infeed: 30mm，50mm，75mm
Speed:6-8m/min
Cutting machine: flying saw cutting with servo motor
Others:High pressure foaming machine

Thickness: 0.3-0.4mm
Stations:36
Cutting type:Fly saw cutting with servo motor
Transmission by gear box
Working speed: 15m/min

One-piece frame;
High precision;
Hydraulic cutting;
Germany COPRA software for professional roller design;
Quick change system for producing pipes with different specifications.

Stations: 28
Transmission by gear
Cutting type: Hydraulic system
Working speed: 4-6m/min (including cutting and punching)
