SPECIAL TUBE ROLL FORMING MACHINE (FAST SPEED)

Thickness: 0.3-0.6mm
Forming stations: 12
Drive type: gear transmission system
Forming speed: 20-25m/min

  • HZ

  • HUAZHONG

  • 8455229090

Availability:
Inquire

PRODUCT DESCRIPTION

Uncoiler---Roll forming---Run out table

TECHNICAL DETAILS

Frame: One-piece frame

Embedded hydraulic cabinet: Delta PLC control system, Delta inverter

Cantilever console: Delta touch screen

Thickness: 0.3-0.6mm

Coil width: φ49 round tube

Forming station: 12

Main motor power: 30KW, 380V, 50HZ, 3Phase

Forming speed: 20-25m/min

Drive type: gear transmission system

MACHINE PHOTOS

Special tube roll forming machine (4)

Special tube roll forming machine (5)

Special tube roll forming machine (10)

Special tube roll forming machine (3)

VIDEO

FACTORY INFORMATION

客户照片1

客户照片2

special tube roll forming machine tube roll forming machine Pipe Roll Forming Machine
