CABLE TRAY SUPPORT ROLL FORMING MACHINE

Thickness:1.5-2.0mm
Forming station: 16
Cutting type:Hydraulic cutting
Drive type:140 gear box transmission
Forming speed: 10-15m/min

  • HUAZHONG

  • HUAZHONG

  • 8455229090

Availability:
Inquire

PRODUCT DESCRIPTION

Uncoiler---Feeding guide---Roll forming---Hydraulic cutting---Run out table

TECHNICAL DETAILS

Frame: One-piece steel frame

Uncoiler: 3 Tons electric

Forming station: 16

Driving type: 140 gear box transmission

Main motor power: 11KW ,220/380V,50/60HZ,3 Phase, Omate

Hydraulic system: 5.5KW, 1 station, 24MPa

Electrical system: Delta external electric cabinet

Cutting type: Hydraulic cutting

Punching system: Hydraulic punching

Material thickness: 1.5-2.0mm

Material width: 300mm

Forming speed: 10-15m/min

Run out: 1m run out table with ramp and reclaiming frame

MACHINE PHOTOS

Cable tray support roll forming machine (9)Cable tray support roll forming machine (3)Cable tray support roll forming machine (5)
