HEAT PRESERVATION GARAGE DOOR AUTOMATIC PRODUCTION LINE

THICKNESS:0.3-0.5mm
PANEL THICKNESS:40mm/50mm(CUSTOMIZED)
SPEED:3-8m/min CONTROLLED BY INVERTER
LENGTH OF COMBINED CONVEYOR:24m
HEATING TEMP:30-60AUTO CONTROLLER
  • HUAZHONG

  • HUAZHONG

  • 8455229090

Availability:

PRODUCT DESCRIPTION

Full automatic model of HZPU-600 series double metal polyurethane continuous production line for garage door consists of: combined motor, upper/down roll formers, high press PU injection machine, 200T hydraulic machine, auto fly saw cutting system. The working process is spraying liquid PU material into roll formed upper and down panel under high pressure, foam molding by PVC plastic double conveyor in the combined motor, fly saw cutting ad then putting out. The whole machine uses PLC automatic control system, from un-coiler, feeding to putting out. This continuous production line has the advantages of high level of automation, low level of labor input, simple structure, easy to use, low investment and fast economic return, enabling itself the top option in the building material industry.

18

TECHNICAL DETAILS

MATERIAL:G330
THICKNESS:0.3-0.5mm
WIDTH:500-700mm
PU MATERIAL:POLYURETHANE A/B
DOOR PANEL SPECIFICATION
WIDTH:400-600mm ADJUSTABLE
PANEL THICKNESS:40mm/50mm(CUSTOMIZED)
LENGTH:2000mm-16000m CAN BE SETTING
PUDENSITY:35-50Kg/M³ADJUSTABLE
MACHINE TECHNICAL PARAMETER
SPEED:3-8m/min CONTROLLED BY INVERTER
LENGTH OF COMBINED CONVEYOR:24m
HEATING TEMP:30-60AUTO CONTROLLER
TOTAL POWER:100Kw
OVERALL DIMENSION:85m×2m×5m FULL LINE
WORKSHOP DIMENSION:100m×15m×7m 5T BREDGE CRANE IS REQUIRED

MACHINE PHOTOS

HEAT PRESERVATION GARAGE DOOR AUTOMATIC PRODUCTION LINE-1
