U CHANNEL ROLL FORMING MACHINE

Thickness: 0.6mm
Forming station: 12
Cutting type:hydraulic disk fly saw cutting
Drive type: Gear transmission
Forming speed:25m/min

  • HUAZHONG
  • HUAZHONG
  • 8455229090

PRODUCT DESCRIPTION

Uncoiler---Feeding guide---Roll forming---Hydraulic cutting with servo motor---Run out table

TECHNICAL DETAILS

Frame: One-piece steel frame

Uncoiler: 2 Tons

Forming station: 12

Driving type: gear transmission

Main motor power: 7.5kw,220/380V,50/60HZ,3 Phase

Hydraulic system: 4kw

Electrical system: Siemens control system

Cutting type: Hydraulic cutting with servo motor

Material thickness: 0.6mm

Forming speed: 25m/min

Run out: 6m run out table

MACHINE PHOTOS

U channel roll forming machine (2)U channel roll forming machine (8)
