SPIRAL ORBIT MACHINE FOR HIGH SPEED DOOR

Used for high speed door machine
Suitable plate of the bending : Aluminum alloy
Produce products radius: Through the PLC control
Working speed: 2-3 sets/min
  • HUAZHONG

  • HUAZHONG

  • 8455229090

Availability:

Product Description

Suitable plate of the bending : Aluminum alloy
Working speed:  2-3 sets/min
Roller material: CR12, HRC 60 Degree. roller diameter φ120
Material of principal axis: Fine steel modulation processing of 45(axis diameter:φ50)


  Sprocket wheel: 45 steel high-frequencies quench

Motor power: 2.2 KW 380V 50HZ 3Phase
Lifting synchronous motor:1.5KW Servo motor


  Working radius≤500mm

  Automatic bending

Produce products radius: Through the PLC control
Overall Dimension:  500mmX500mmX1200mm
Total weight:  0.8 ton approximately
